Edenya Ice Pro 3-way under-sink cooler for the dispensing of:
- Natural water environment
- Cold natural water
- Cold sparkling water
Sub-wash microfiltration to be installed upstream of the plant. We recommend using a filter Edenya AG Medium
Dry hydraulic cooling system, without forced ventilation.
Galvanized sheet metal body, powder coated. Control unit with anti-flooding and electronic temperature regulation, 2.2 liter carbonator.
Installation kit and tubes included in the package.
Included in the scope of delivery is a H2O pressure regulator to be installed before the plant to optimize the work of the machine.
Technical characteristics
- Power supply: 220V 50Hz
- Absorption: 200W (in operation by 180W 220V 50HZ motor)
- Pump: Booster 240 LT/H certified D.M. 174
- Compressor: 1/8 HP
- Carbonator: 2.2 litres
- Carbon Block Composite Filter
- Cold water production: 15 l/h with inlet T.22°C and outlet 6°C
- Working pressure: +/- 10 bar
- Water pressure: min 2- max 5 bar
- Total solids dissolved in input: max 2000 Mg/l
- Allowed pH water intake: min 3 max 11
- Hydraulic dry cooling without forced ventilation
- Body shop in galvanized sheet
- Control unit with anti-flooding and electronic temperature regulation
- Weight: 15 kg
- Dimensions: H 45.5 cm – W 22.5 cm – D 34.5 cm
INSTALLATION
Area of placement
The area of use of the Ice Pro machine must comply with the following requirements:
- The position chosen for use shall allow a smooth connection of the plug to the power line of the environment in which it is used.
- The position chosen for use shall allow a smooth connection of the machine to the water system of the environment in which it is used.
- The connecting cables shall not be placed on the floor but shall be suspended or recessed in suitable channels.
- The connecting cables must not be placed in a position that could hinder people from running into them, causing injury and breaking the machine.
- The environment must be free of dust, corrosive gases and oils.
- The maximum altitude in which the Ice Pro machine can be used is 1000m.
- Store indoors in a dry environment.
Temperature
- Operating: 5 °C to 25 °C
- Not in use: -5°C to 50°C.
- During storage and before use: -5 °C to 50 °C.
Physical installation procedure
Connect the machine to the water supply via the IN water connection at the rear. Open the water tap and check that there is no leakage.
Connection to the electricity grid
To connect the machine to the power supply it is sufficient:
- Insert the power cord connector into the imput in the machine.
- Plug the power into a suitable outlet.
